ZCM1000C – Automatic Tape Dispenser for Glass Cloth and Hard-to-Handle Adhesive Tapes
In electronics manufacturing, transformer winding, and automotive wire harness production, certain tape materials consistently resist standard dispensing equipment. Glass cloth tapes, thin fiberglass-reinforced bands, and other structurally delicate materials flutter, bunch, or produce ragged cuts on conventional machines. START International engineered the ZCM1000C to solve exactly this problem — with a purpose-built cutting head that keeps flimsy and woven tapes under control from feed to cut.
Specialty Engineering Where It Counts
The ZCM1000C shares the same proven platform as the ZCM1000 but incorporates a structurally modified cutting head specifically designed for glass cloth tapes. This prevents lateral drift of thin, textured materials during advancement and ensures that the guillotine cut produces a clean, fray-free edge — even on woven substrates that would generate scrap on a standard dispenser. The outcome: consistent quality, zero manual rework, and uninterrupted production flow.
Fully Automated Dispensing – No Operator Intervention Required
The integrated photocell continuously monitors the output area. The moment a tape piece is removed, the next piece is fed and positioned automatically — ready for immediate use. For applications requiring manual control, a push-button trigger is available at any time. The target cut length is programmed once via the digital LED panel, stored permanently, and applied with a repeatability of ±1 mm across the full range of 20 to 999 mm.
Target Materials and Industries
The ZCM1000C is the dispenser of choice wherever standard machines fall short:
-
Electronics / PCB: Glass cloth masking tape, Kapton®-like films, board protection
-
Automotive: Wire harness insulation tapes, thin woven banding materials
-
Transformer & Motor Manufacturing: Fiberglass coil winding tapes, insulation layers
-
Renewable Energy: Thin structural tapes in solar and wind component assembly
-
General Industry: Any flimsy or lightweight woven adhesive tape requiring precise cut lengths
Global Deployment – Built to Last
The ZCM1000C is constructed on the same rugged foundation trusted by manufacturers worldwide for over three decades. The steel frame and antistatic, flame-retardant composite housing (auto-ignition temperature: 480 °C) ensure reliable operation in electrically sensitive and demanding production environments. Blade life reaches up to 200,000 cuts, the adjustable pressure roller accommodates varying tape thicknesses, and the 3-in-1 core holder (25 / 35 / 76 mm) enables tool-free roll changes in seconds.
For the European market, the ZCM1000C-2 (230 V / 50 Hz, CE certified) is the standard supply version. The compact footprint of 24.5 × 13.5 × 16.0 cm and a weight of just 2.54 kg make it suitable for any workstation layout.
Free Material Testing
Unsure whether the ZCM1000C is the right fit for your specific tape? START International tests your material free of charge and without obligation. You receive a written test report with a tailored machine recommendation. Contact us at info@startinternational.eu or submit a material evaluation request via our website.
What's in the Box
- ZCM1000C Electric Tape Dispenser
- Product manual
- Silicone oil
- Safety guard
Technical Specifications – ZCM1000C
| Parameter |
Specification |
| Model designation |
ZCM1000C (230 V EU version: ZCM1000C-2) |
| Product category |
Electric tape dispenser – glass cloth & flimsy tape specialty version |
| Compatible tape width |
7 – 51 mm (0.28" – 2.0") |
| Programmable cut range |
20 – 999 mm (0.79" – 39") |
| Max. roll outer diameter |
178 mm (7") |
| Core holder (included) |
3-in-1: 25 mm / 35 mm / 76 mm |
| Cut accuracy |
±1 mm (material-dependent) |
| Tape feed speed |
14.5 cm/s (5.7"/s) |
| Cutting head |
Specialty design for glass cloth and flimsy tapes |
| Operating modes |
Automatic (photocell) / Manual (push-button) |
| Cutting mechanism |
Guillotine (straight, fray-free cut edge) |
| Blade life |
Up to 200,000 cuts (material-dependent) |
| Length setting |
Digital (LED), manually overridable |
| Pressure roller |
Adjustable (for varying tape thicknesses) |
| Frame / Housing |
Steel frame / antistatic flame-retardant composite (480 °C) |
| Dimensions (L × W × H) |
24.5 × 13.5 × 16.0 cm (9.7" × 5.3" × 6.3") |
| Weight |
2.54 kg (5.6 lbs) |
| Rated voltage |
117 V, 50/60 Hz, <1 A / 230 V, 50/60 Hz (ZCM1000C-2) |
| Certification |
CE (all 230 V models) |
| Country of manufacture |
Japan |
| Recommended accessories |
ZFOOTSWITCH, zcM1000P026 (reel stand), zcM1000P550E (dual cutting head) |
| Box contents |
Unit, product manual, silicone oil, safety guard |
The ZCM1000C is the recommended solution for glass cloth and flimsy adhesive tapes. For standard pressure-sensitive tapes, see the ZCM1000. For double-sided, high-tack, and foam tapes, the ZCM1000-NS is available. All ZCM1000 variants are listed on our product overview page.
